Smart Cellphone Storage Locker with Card-swipe System AL5001CD40B

Smart Cellphone Storage Locker with Card-swipe System AL5001CD40B

  • Model: AL5001CD40B
  • Material: Cold Rolled Steel Sheets
  • Brand: Aituo
  • Delivery: 25-30 Days
  • Warranty:1 year

INQUIRY NOW

×Enter your message





    Smart Card Swipe Locker: AL5001CD40B

    Aituo Smart Storage Locker can add networking module, realize networking function, manage user's status of use through networking software, realize remote control, query statistics, report printing and other functions, and can be connected with third-party software.

    Aituo Electronic Card Swipe Locker uses RFID technology. Very easy to manage by the owners, also very conveniently to operate by the users.

    How is Aituo locker production?

    Aituo Production Mahine Line

    Specification:
    Model Number ALAL5001CD40B
    Product Name Smart Cellphone Storage Locker
    Material High Quality Galvanized Steel
    Front door/side panel: 1.2mm
    Level panel:1.0mm
    Back panel:0.8mm
    Screen /
    Computer Industrial host, Android system,RK3288/4 core frequency 1.8 Ghz,2G Ram, 8G EMMC, RS485 Port*2, 4G and WIFI model is optional
    Barcode Reader 2D Barcode Reader
    Lockers (Doors) Secured Electronic Lock
    Speakers Bi-channel Speakers
    Kiosk Size H2020*W500*D500(mm)
    Sub Cabinet Size H2020*W940*D500(mm)
    Kiosk Door N/A
    Sub Cabinet Door 20 Doors
    XL box: H400*W425*D500mm x 2
    L box: H300*W425*D500mm x 2
    M box: H200*W425*D500mm x 6
    S box: H100*W425*D500mm x 10
    Storage temperature -10℃ -- 50 ℃
    Working temperature 0℃ -- 50 ℃
    Net Weight: Kiosk:85Kgs/Sub Cabinet:128Kgs
    Gross Weight: Kiosk:115Kgs/Sub Cabinet:168Kgs

    How does it work?
        Step 1: Customer press "Save" button and swipe the IC card.
        Step 2: The door open.
        Step 3: Customer put the package into the box and close the door.
        Step 4: Customer press "Take out" button and swipe the IC card again.
        Step 5: Customer take out the package or bags and close the door.

    Recogition System Option:

    OEM Color Option:

    OEM Size for Customer:

    Application: Enterprises and institutions, libraries, hospitals, water parks and theme parks.

    We use high Quality Lock Board and Lock System.
