Smart Locker PCB Board Multi Function Lock Control Board ATL-Q1

Smart Locker PCB Board Multi Function Lock Control Board ATL-Q1

  • Model:ATL-Q1
  • Brand:AITUOIoT
  • Delivery:7-15 days
  • Warranty:2 years


×Enter your message

    Function Description:

    --Industrial design. 24VDC is recommended for the control board

    --Each channel can be controlled individually or centrally by one instruction.

    --Lightning protection, short circuit protection and reverse connection protection.


    1, two electromagnetic lock control, lock opening 300ms (with feedback function)

    2, 4-way output function, can be connected with lighting, disinfection, indicator light and other low power equipment

    3, 2 relay, can be connected to heating equipment, refrigeration equipment, fan and other high power DC/AC equipment

    4, 1 channel 18B20 temperature sensor

    5, 1 5V item detection function, can be connected to infrared detection, pressure detection and other sensors

    --Model Number:ATL-Q1

    --Operating voltage: DC 12V/24V

    --Operating temperature: -40℃~+85℃

    --Read lock feedback: supported

    --Unlock output time: 300 ms

    --Standby power consumption: < 1W

    --Communication interface: RS485 protocol

    --Program upgrade interface: TTL serial port protocol

    --Baud rate: 9600

    --Drive lock current: Max. 3A

    --Supports 12V/24V magnetic lock

    --Number of layers: Multiple layers

    --Flame retardant property: V2 board

    --Supports cascading of multiple boards

    --Multi-function: can support heating, disinfection, lighting, indicator light, temperature, item detection and so on

    --Net weight: 70.09 g

    --Size: L125mm * W80mm


    It can be used for smart multifuction lockers , such as food lockers which need multifuction like heating, disinfection, lighting, indicator light, temperature, item detection and so on
